Description:
BZCQ Series Vacuum Degassers are able to service the needs of any application. It can quickly remove all kinds of gases intruding into drilling mud, and play a very important role in restoring the proportion of mud and stabilizing the performance of mud. At the same time, it can also be used as a high-power mixer, suitable for all kinds of mud circulation purification system.
Features & Benefits:
1. It can quickly remove the gas in the gas invasion mud, restore the mud proportion and stabilize the mud performance.
2. Can be used as a high-power mixer.
3. Compact design, small footprint.
4. It consumes less power than similar foreign products under the same processing capacity.
5. The unique structure design directly after the treatment of mud discharge, without the need to equip with high-power centrifugal pump.
Technical Parameter:
Model
BBZCQ240
BBZCQ270
BBZCQ300
BBZCQ360
Body Diameter
700mm
800mm
900mm
1000mm
Treatment Capacity
240m3/h
270m3/h
300m3/h
360m3/h
Vacuum Degree
-0.03~-0.045MPa
-0.03~-0.045MPa
-0.03~-0.045MPa
-0.03~-0.045MPa
Transmission Ratio
1.68
1.68
1.68
1.72
Degassing Efficiency
≥95%
≥95%
≥95%
≥95%
Main Motor Power
15kw
22kw
30kw
37kw
Vacuum Pump Power
2.2kw
3kw
4kw
7.5kw
Impeller Speed
860r/min
870r/min
876r/min
880r/min
Ex Stand
ExdIIBt4 / IECEX / A-TEX
ExdIIBt4 / IECEX / A-TEX
ExdIIBt4 / IECEX / A-TEX
ExdIIBt4 / IECEX / A-TEX
Weight
1100kg
1350kg
1650kg
1800kg
Dimension
1750×860×1500mm
2000×1000×1670mm
2250×1330×1650mm
2400×1500×1850mm
